Infinity





Product testing performed with DraXxus Paintballs





What do you think?
Add your comments in WARPIG's TECH TALK FORUMS.


Infinity Legend
by Bill Mills - Photos by Dawn Mills - April 2007

Overview - How It Works - Disassembly - Testing - Raw Test Data

RAW TEST DATA

Velocity comparison between 1bps and 12 bps.
30 shot strings fired under microprocessor control.
DraXxus Hellfire paint.
Crossfire screw in compressed air system.
Stock factory Dwell and ROF settings.
Velocities listed in feet per second.

ShotNumber 1 bps 12 bps
1 280.2 298.6
2 283.8 286.2
3 285.2 285.4
4 291.0 282.4
5 287.8 288.8
6 293.2 289.6
7 290.4 290.0
8 290.8 282.4
9 287.6 210.8
10 288.2 263.0
11 295.4 291.6
12 287.0 288.6
13 283.2 285.2
14 290.4 285.0
15 285.0 281.4
16 282.6 283.8
17 287.2 284.4
18 283.4 274.0
19 292.2 279.0
20 289.6 280.0
21 286.4 274.0
22 286.0 270.2
23 289.4 281.0
24 282.6 280.2
25 284.8 275.6
26 287.2 279.2
27 289.0 280.6
28 290.8 277.0
29 283.8 287.4
30 289.0 278.4
High: 295.4 298.6
Low: 280.2 210.8
E.S.: 15.2 87.8
Ave.: 287.4

279.6

S.D.: 3.4 14.6
95%:
±1.0
±6.0

Understanding the Summary Data

High: This represents the highest velocity in the recorded string of shots.

Low: This represents the lowest velocity in the recorded string of shots.

E.S.: Extreme Spread - this is the difference in velocity between the highest velocity shot and the lowest velocity shot.

Ave: Average - this is the average velocity of the string of shots. This is the number to look at to compare whether velocity is increased overall, or decreased overall by a change in a variable.

S.D.: Standard Deviation - S.D. Is a mathematicall way of expressing how close most of the shots are to the average. The lower the Standard Deviation is, the more consistent the velocity is.

95%: This is an easier to understand way of expressing consistency. Statistically, there is a 95% chance than a given shot will vary this amount or less from the average.



20 shot target strings fired at 1bps, at paper
targets from a distance of 75 feet with the Ion
locked on a Custom Cylinders stand.

Stock Barrel

Freak Barrel - All American Tip - 0.687" Insert
